WB110C Spoke Load Cell 3t〜15t

Product Type

a

Model

b

Elastomer Class

c

Capacity (kg)

d

Certification/Area

e

Temperature

f

Load Cell Accuracy

g

Load Cell Cable Length

h

Backup

i

LW-Load cell

A-Analog Load cell

WB110C

(Blank): Stainless steel 2Cr14Ni

3, 5, 7.5, 10, 15

N: Standard

X: Explosion-proof

S: Normal temperature

C3

6m

A: Standard, output sensitivity 2.0 mV/V

F: Customization

Specifications

Model

WB110C

Rated capacity

3

5

7.5

10

15

Sensitivity

mV/V

2±0.002

Accuracy class

C3

Repeatability error

% R.C.

≤0.01

Lag

% R.C.

≤0.03

Non-linearity

% R.C.

≤0.03

Creep (30 minutes)

% R.C.

≤0.02

Zero output

% R.C.

≤1

Temperature compensation range

°C

-10~+40

Opeclassification temperature range

°C

-40~+65

Temperature coefficient of sensitivity

% R.C./°C

≤0.003

Zero temperature coefficient

% R.C./°C

≤0.003

Input impedance

Ω

780±10

Output impedance

Ω

700±1

Insulation resistance

MΩ

≥5000 (100V DC)

Recommended excitation voltage

V (DC/AC)

5~15

Maximum excitation voltage

V (DC/AC)

20

Safety overload

% R.C.

150

Extreme overload

% R.C.

300

IP Class

IP68

Cable length

m

6

Recommended Bolts

Bolt size

M8

M10

Strength class

Class 8.8 or above

Tightening torque

Nm

25

50
