Basic Info
  • Factory Location: taizhou,zhejiang

    Main Sales Markets: Central/South America,Asia,Middle East

  • Packaging Information: Carton or Pallet

  • Sample Provided: no

    Payment Terms: T/T

    Quick Detail

    Place of Origin:Zhejiang, China (Mainland)

    Brand Name:TSVP

    Fuel:Vacuum pump oil

    Color:Optional

    Packaging Details:Carton or Pallet

    Port: Ningbo



    Product Introduction

    • Small volume,low weight and low noise

    • Equipped with gas ballast valve to pump a little water vapor

    • Equipped with oil anti-return device

    • 2XZ-2 with small caliber,2XZ-4 pump with vacuum drying oven,freezing dry machine and printing machine

    • Equipped with small caliver transforming joints and KF joints



    Size Details

    QQ截图20191129093611

    1(001)





    Technical Data

    Model

    2XZ-0.5

    2XZ-1

    2XZ-2

    2XZ-4

    Pumping speed(L/s)

    0.5

    1

    2

    4

    Ultimate pressure(Pa)

    Partial pressure

    ≤6×10-2

    ≤6×10-2

    ≤6×10-2

    ≤6×10-2

    Total pressure

    ≤1.33

    ≤1.33

    ≤1.33

    ≤1.33

    Rotary speed(r/min)

    1400

    1400

    1400

    1400

    Rated Power(kw)

    0.18

    0.25

    0.37

    0.55

    Power Supply

    220V/380V

    220V/380V

    220V/380V

    220V/380V

    Connector

    φ20(KF-16)

    φ20(KF-16)

    φ30(KF-25)

    φ30(KF-25)

    Noise level(db a)

    65

    65

    66

    68

    Oil capacity(L)

    0.6

    0.7

    1

    1.2

    Dimensions(mm)

    447×150×260

    469×150×260

    514×168×285

    565×168×285

    G.W./N.W.(kg)

    17/16

    18/17

    22/20

    24/22
